Stanford Materials Corporation (SMC) supplies high-performance Scandium Planar Targets with a purity level of 99.9%, designed for advanced thin-film deposition processes. Custom sizes and rigorous quality checks ensure reliable performance for both research applications and industrial use.
SMC’s scandium targets are made from 99.9% pure scandium metal, available in diameters ranging from 50 mm to 200 mm, with thicknesses between 3 mm and 10 mm. With a grain size smaller than 50 µm and a density above 95%, these targets provide consistent sputtering performance, essential for the production of high-quality films. Each target is vacuum-sealed in argon-filled containers and validated through ICP-MS and XRD to meet ASTM F3091 standards.
Note: The data above is based on theoretical estimates. For precise specifications, please contact SMC for custom inquiries.
SMC’s scandium planar targets are carefully packaged according to the size and specifications of each material. Smaller items are packed securely in PP boxes, and larger items are housed in customized wooden crates to ensure safe shipping. Proper cushioning materials are used to protect the items during transit.
Packaging Types: Cartons, Wooden Boxes, or Custom Solutions.
Q1: What purity grades are available for scandium targets?
Q2: How should scandium targets be stored?
Q3: Are your scandium targets compatible with magnetron sputtering systems?
| Feature | Scandium Rotary Target | Scandium Planar Target |
|---|---|---|
| Material Utilization | Up to 80-90% | Around 30-40% |
| Service Life | Longer | Shorter |
| Coating Uniformity | More uniform | May have variations |
| Production Cost | Higher initial cost | Lower initial cost |
| Applications | Large-area coatings | Small-area coatings |
| Sputtering Stability | More stable | Less stable |
| Compatible Equipment | Rotary sputtering systems | Traditional planar systems |
